Short Description:

Features
1. It has a multi-layer sand control filter device and advanced sand control performance, which can well block sand in the underground layer. It is mainly used in the underground;
2. The pore size of the screen is uniform, and the permeability and anti-blocking performance are particularly high;
3. The oil filtering area is larger, which reduces the flow resistance and increases the oil yield;
4. The screen is made of stainless steel and has excellent corrosion resistance. It can resist acid, alkali and salt corrosion and meet the special requirements of oil wells;


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • High Standard Low Price Vibrating Shale Shaker Screen

    1. The mesh numbers of each layer of stainless steel mesh in the flat vibrating screen are different. Accurate and reasonable matching can make the screening effect more detailed. The mesh numbers of the stainless steel mesh and the punching shape and opening rate of the metal lining plate are different. size, and strive to obtain the largest effective filtration area while ensuring the intensity of use.

    2. The stainless steel screen and the metal lining are tightly bonded into one, which enhances the strength of the entire flat vibrating screen and prolongs its use time.

    High Standard Low Price Vibrating Shale Shaker Screen
    Features
    High Standard Low Price Vibrating Shale Shaker Screen

    3. The mesh of the metal lining plate divides the stainless steel screen into multiple independent small mesh surfaces, which can prevent excessive expansion of local damage. At the same time, it is equipped with a special rubber match to repair the damaged mesh surface, which can save time and reduce usage costs.

    Our company has rich production experience and mature technology and can produce various specifications of flat vibrating screens according to the needs of different customers.

    Flat plate vibrating screen (hook edge vibrating screen) is currently the most commonly used vibrating screen and can be widely used in drilling operations under different conditions.

    Usually, a flat vibrating screen is composed of 2 to 3 layers of stainless steel screens bonded to a perforated metal lining. The characteristics of this type of vibrating screen are as follows:

    Specification



    Screen model

       Mesh range

        Dimensions       (width x length)

    Suitable vibrating screen machine models

    HSP-1 20-325                    697×1053mm                D2000
    HSP-2 20-325 695×1050mm D500
    HSP-3 20-325 697× 846 mm D313M
    HSP-4 20-325 903×1155mm BEM-3
    HSP-5 20-325 1212×1141mm ALS-2
    HSP-6 20-325 915×1150mm LCM-2D
    HSP-7 20-325 700×1165mm S250



    API RP 13C(ISO 13501)
    D100 sieved particles (microns)                API screen number
    >780.0 to 925.0 API 20
    >655.0 to 780.0 API 25
    >550.0 to 655.0 API 30
    >462.5 to 550.0 API 35
    >390.0 to 462.5 API 40
    >327.5 to 390.0 API 45
    >275.0 to 327.5 API 50
    >231.0 to 275.0 API 60
    >196.0 to 231.0 API 70
