Outdoor environment diamond plate work platforms

Short Description:

The anti-skid checkered plate is a kind of plate with anti-skid function, which is usually used in indoor and outdoor floors, stairs, steps, runways and other places. Its surface is covered with special patterns, which can increase the friction when people walk on it and prevent slipping or falling.
The material of the non-slip pattern plate usually includes quartz sand, aluminum alloy, rubber, polyurethane, etc., and different materials and patterns can be selected according to different usage occasions and needs.

Outdoor environment diamond plate work platforms

Product information

The checkered plate has many advantages such as beautiful appearance, anti-skid, enhanced performance, and steel saving.

It is widely used in transportation, construction, decoration, floor around equipment, machinery, shipbuilding and other fields.

Generally speaking, the user does not have high requirements on the mechanical properties and mechanical properties of the checkered plate, so the quality of the checkered plate is mainly manifested in the flowering rate of the pattern, the height of the pattern, and the height difference of the pattern.

The commonly used thicknesses on the market range from 2.0-8mm, and the common widths are 1250 and 1500mm.

Features

Anti-skid checkered plate is a non-slip material with the following characteristics:
1. Good anti-slip performance: The surface of the anti-slip pattern plate has a special pattern design, which can increase friction and improve anti-slip performance, which can effectively reduce the risk of people or items slipping.

2. Strong wear resistance: The non-slip tread plate is made of high-strength material, which has good wear resistance and corrosion resistance, and can be used for a long time in harsh environments.

3. Easy to install: The non-slip checkered plate can be cut and spliced according to your needs. The installation is simple and convenient, and you can install it yourself without professional technicians. Of course, if you need installation guidance, we are also happy to help you.

4. Beautiful appearance: the surface of the non-slip checkered plate has a variety of colors and patterns to choose from, which can be coordinated with the surrounding environment and is beautiful and generous.

5. Wide range of applications: Anti-slip tread plates have a wide range of applications and can be applied to various places, such as stairs, corridors, factories, workshops, docks, ships, etc., which can effectively prevent people or objects from slipping and falling accidents.

Diamond Plate Theoretical Weight Table(mm)
Basic thickness	Basic thickness tolerance	Theoretical quality(kg/m²)
		Diamond	Lentils	Round bean
2.5	±0.3	21.6	21.3	21.1
3.O	±O.3	25.6	24.4	24.3
3.5	土0.3	29.5	28.4	28.3
4.O	±O.4	33.4	32.4	32.3
4.5	±O.4	38.6	38.3	36.2
5.O	+O.4	42.3	40.5	40.2
	-O.5
5.5	+O.4	46.2	44.3	44.1
	-O.5
6	+O.5	50.1	48.4	48.1
	-O.6
7	0.6	59	58	52.4
	-O.7
8	+O.6	66.8	65.8	56.2
	-O.8

Application

Stairs and walkways: checkered plates are usually used for stairs or ramps in industrial areas, especially in rainy and snowy weather, or when there are liquids such as oil and water attached, which help reduce the possibility of sliding on the metal and increase friction To improve the safety of passing by.

Vehicles and trailers: Most pickup truck owners can attest to how often they get in and out of their trucks. As a result, checker plates are often used as critical sections on bumpers, truck beds, or trailers to help reduce slippage when stepping on the vehicle, while also providing traction for pulling or pushing material on or off the truck.

request a quote

Complete control over the product enables us to ensure Customers receive the highest quality prices and services. we Take pride in everything we do to serve our customers.
